INPA: UIF (User Information Field) Reportġ-Open INPA>select your car model (E60)>Functional Jobs>F3 UIFĢ-You'll see a list of all control units with their ZUSB number and VINĤ-Identify the ZUSB numbers without your VIN and copy from the PDF and close INPAĥ-Open WinKFP (Load SPDaten files google it)ĩ-this will go straight to the right ZUSBġ0-Then enter your full VIN and then click on doneġ1-Double check that the module your going to flash it's safe to flash with your cable and the battery needs to be connect to another power sourceġ2-Click on update ZUSB (this will flash the module with SPDaten files and re-write the VIN)ġ4-Load profile -> Expertmode -> F1 -> F3 -> choose E60 from the list -> choose any module you want from this list -> now click F6 Back -> select F4 Process ECU -> choose Module -> now click ReadECU -> close the notepad window that showed up after the module was read.ġ5-Press F5 for basic functions -> Select "coapiReadSgGetFswPsw" and click Ok -> Select F2 "job" select SG_CODIEREN and press ok -> Press F3 Execute job and wait for the buttons to become active, when active it's all done. Step by Step to edit VIN, Flash, Code to Default, Clear Errors and Start System Time of the Airbag Gateway Module.
